xStack® DES-3528/DES-3552 Series Layer 2 Stackable Fast Ethernet Managed Switch Web UI Reference Guide
802.1p Map Settings
This window is used to enable 802.1p Map Settings.
To view the following window, click QoS > 802.1p Settings > 802.1p Map Settings, as shown below:
The fields that can be configured are described below:
Parameter Description
Unit
Select the unit to configure.
From Port / To Port
A consecutive group of ports may be configured starting with the selected port.
Priority List (0-7)
Enter the priority list from 0 to 7.
Color
Specify the color Red, Yellow or Green.
Click the Apply button to accept the changes made.
149
