xStack® DES-3528/DES-3552 Series Layer 2 Stackable Fast Ethernet Managed Switch Web UI Reference Guide
Figure 8-17 Authenticator Diagnostics window
The fields that can be configured are described below:
Parameter Description
Unit
Select the unit to be displayed.
Port
Select the port to be displayed.
Click the Apply button to accept the changes made.
NOTE: The Authenticator Diagnostics cannot be viewed on the Switch unless 802.1X is enabled. To
enable 802.1X, go to Security > 802.1X > 802.1X Global Settings, and select Enabled from
the Authentication State drop-down menu.
Initialize Port(s)
Existing 802.1X port and MAC settings are displayed and can be configured using the window below.
To view this window, click Security > 802.1X > Initialize Port(s), as shown below.
213
