xStack® DES-3528/DES-3552 Series Layer 2 Stackable Fast Ethernet Managed Switch Web UI Reference Guide
Figure 8-14 Authenticator State window
The fields that can be configured are described below:
Parameter Description
Unit
Select the unit to be displayed.
Port
Select a port to be displayed.
Click the Find button to locate a specific entry based on the information entered.
Click the Refresh button to refresh the display table so that new entries will appear.
NOTE: The Authenticator State cannot be viewed on the Switch unless 802.1X is enabled. To enable
802.1X, go to Security > 802.1X > 802.1X Global Settings, and select Enabled from the
Authentication State drop-down menu.
Authenticator Statistics
This table contains the statistics objects for the Authenticator PAE associated with each port. An entry appears in this
table for each port that supports the Authenticator function.
To view the Authenticator Statistics, click Security > 802.1X > Authenticator Statistics, as shown below:
