xStack® DES-3528/DES-3552 Series Layer 2 Stackable Fast Ethernet Managed Switch Web UI Reference Guide
Click the Delete button to remove the specific entry.
After clicking the Group List
link, the following page will appear:
Figure 4-71 Multicast Group Profile Multicast Address Settings window
The fields that can be configured are described below:
Parameter Description
Multicast Address List Enter the multicast address list.
Click the Add button to add a new entry based on the information entered.
Click the <<Back button to discard the changes made and return to the previous page.
Click the Delete button to remove the specific entry.
MLD Snooping Multicast VLAN Settings
Users can add, delete, or configure the MLD snooping multicast VLAN on this page.
To view the following window, click L2 Features > L2 Multicast Control > Multicast VLAN > MLD Snooping
Multicast Group VLAN Settings, as shown below:
Figure 4-72 MLD Snooping Multicast VLAN Settings window
The fields that can be configured are described below:
Parameter Description
MLD Multicast VLAN
State
Click the radio buttons to enable or disable the MLD multicast VLAN state.
MLD Multicast VLAN
Forward Unmatched
Click the radio buttons to enable or disable the MLD multicast VLAN Forward
Unmatched state.
VLAN Name
Enter the VLAN name used.
121
