xStack® DES-3528/DES-3552 Series Layer 2 Stackable Fast Ethernet Managed Switch Web UI Reference Guide
Figure 4-16 VLAN Precedence Settings window
The following parameters can be configured:
Parameter Description
Unit
Select a unit to be configured.
From Port / To Port
Specify the port or range of ports to configure.
VLAN Precedence
Use the drop down menu to select the VLAN precedence, choose either MAC-based VLAN
or Subnet VLAN.
MAC-based VLAN – Specifies that the MAC-based VLAN classification is given precedence
over the subnet-based VLAN classification.
Subnet VLAN – Specifies that the subnet-based VLAN classification is given precedence
over the MAC-based VLAN classification.
Click Apply to implement changes made.
VLAN Counter Settings
To view the following window, click L2 Features > VLAN > VLAN Counter Settings, as shown below:
72
