xStack® DES-3528/DES-3552 Series Layer 2 Stackable Fast Ethernet Managed Switch Web UI Reference Guide
Figure 6-13 QoS Scheduling Mechanism window
The following parameters can be configured:
Parameter Description
Unit
Select the unit to configure.
From Port / To Port
Enter the port or port list to configure.
Scheduling Mechanism
Strict – The highest class of service is the first to process traffic. That is, the highest
class of service will finish before other queues empty.
Weighted Round Robin – Use the weighted round-robin algorithm to handle packets in
an even distribution in priority classes of service.
Click the Apply button to accept the changes made.
NOTE: The settings you assign to the queues, numbers 0-7, represent the IEEE 802.1p priority
tag number. Do not confuse these settings with port numbers.
161
