xStack® DES-3528/DES-3552 Series Layer 2 Stackable Fast Ethernet Managed Switch Web UI Reference Guide
90
The fields that can be configured are described below:
Parameter Description
Unit
Select the unit to configure.
Port
Select the port to configure.
Instance ID
The MSTI ID of the instance to be configured. Enter a value between 0 and 15. An entry
of 0 in this field denotes the CIST (default MSTI).
Internal Path Cost
This parameter is set to represent the relative cost of forwarding packets to specified ports
when an interface is selected within an STP instance. Selecting this parameter with a
value in the range of 1 to 200000000 will set the quickest route when a loop occurs. A
lower Internal cost represents a quicker transmission. Selecting 0 (zero) for this parameter
will set the quickest route automatically and optimally for an interface.
Priority
Enter a value between 0 and 240 to set the priority for the port interface. A higher priority
will designate the interface to forward packets first. A lower number denotes a higher pri-
ority.
Click the Find button to locate a specific entry based on the information entered.
Click the Apply button to accept the changes made.
Click the Edit button to re-configure the specific entry.
