UMN:CLI User Manual

V8102

178

7.4.8 Uploading Syslog File

To upload a syslog file of the external output using FTP or TFTP, use the following com-

mand.

Command

Mode

Description

copy {ftp | tftp} syslog external

sdcard sfu upload [FILENAME ]

Enable

Uploads a syslog file to FTP or TFTP server with the

name configured by user.

FILENAME: log file name

NUM: slot number

copy {ftp | tftp} syslog external

sdcard slot NUM upload [FILE-

NAME ]

7.4.9 Displaying Syslog Configuration

To display the configuration of the syslog, use the following command.

Command

Mode

Description

show syslog [status]

Enable

Global

Shows the configuration of the syslog.

show syslog {volatile | non-

volatile} information

Shows the usage of the area where the received sys-

log messages are stored.

volatile: the area for volatile syslog messages

non-volatile: the area for non-volatile syslog messages
