User Manual UMN:CLI

V8102

593

To clear the existing prefix list entries, use the following command.

Command

Mode

Description

clear ipv6 prefix-list [WORD]

Enable

Global

Clears the counters of all IPv6 prefix lists or an IPv6

prefix with a specified name and prefix.

clear ipv6 prefix-list WORD

X:X::X:X/M

11.3.11 Creating IPv6 Prefix Pool

All pool names muse be unique. Once a pool is configured, it cannot be changed. To

change the configuration, the pool must be removed and recreated. All prefixes already

allocated will also be freed.

To configure a local IPv6 prefix pool, use the following command.

Command

Mode

Description

ipv6 local pool PREFIX-

POOLNAME X:X::X:X/M <2-64>

Global

Sets a domain name.

PREFIX-POOLNAME: prefix-pool name

X:X::X:X/M: IPv6 prefix address

<2-64>: assugbed length (bits)

show ipv6 local pool [PREFIX-

POOLNAME]

Enable

Global

Displays information about any defined IPv6 address

pools.
