User Manual UMN:CLI

V8102

183

7.6.6 Displaying EFM OAM Configuration

To display OAM configuration, use the following command.

Command

Mode

Description

show oam efm

Enable

Global

Shows EFM OAM configuration.

show oam efm link-monitor {lo-

cal | remote} PORTS

Shows the link monitoring status and remote statistics

on the port.

show oam efm local PORTS

Shows local OAM configuration.

show oam efm remote PORTS

Shows remote OAM configuration.

show oam efm variable <0-255>

<0-65535> PORTS

Shows remote OAM variable.

0-255: branch number

0-65535: leaf number
