User Manual UMN:CLI
V8102
779
DM-Request
(server → OLT)
(a) User-Name
(b) User-Password
(c) Dasan-Gpon-Olt-Id
(d) Dasan-Gpon-Onu-Id
(e) Dasan-Gpon-Onu-Model-Name
(f) Dasan-Gpon-Onu-Serial-Num
(g) Dasan-Gpon-Onu-Firmware-Version
Tab. 12.2 RADIUS Authentication Message Type
To configure IP address and key value of RADIUS server for ONU authentication, use the
following command.
onu auth radius-server host
A.B.C.D key WORD [auth-port
<0-65535>]
Specifies an IP address with key value and UDP port of
RADIUS server.
A.B.C.D: RADIUS server IP address
WORD: RADIUS authorization key value
0-65535: UDP port (default: 1812)
onu auth radius-username
{ serial-number | model-name}
Sends the ONU’s serial number-based or its model
name-based ID key value on the authentication mes-
sage to RADIUS server.
serial-number: uses GPON serial number of ONU (de-
fault)
model-name: uses model name of ONU
onu auth radius-password
{ serial-number | model-name}
Sends the ONU’s serial number-based or its model
name-based password on the authentication message
to RADIUS server.
no onu auth radius-server host
A.B.C.D
Deletes the configured RADIUS server address.
To display the information of RADIUS server for ONU authentication, use the following
command.
show onu auth radius-server
Shows the information of RADIUS server for ONU
authentication
You can see the status of ONU authentication via RADIUS server by the debug gpon
rauth command.
To enable/disable the ONU authentication for ONU profile, use the following command.
onu auth-control {enable | disa-
ble }
Enables/disables the authentication control function for
the specified OLT port.
