User Manual UMN:CLI

V8102

313

9.1.4 VLAN Description

To specify a VLAN description, use the following command.

Command

Mode

Description

vlan description VLANS DESC

VLAN

Database

Specifies a VLAN description.

VLANS: VLAN ID (1-4094)

DESC: description

no vlan description VLANS

Deletes a specified description.

To display a specified VLAN description, use the following command.

Command

Mode

Description

show vlan description

Enable

Global

Shows a specified VLAN description.
