Dasan V8102 - Auto Upgrade

To Next Page

To Previous Page

UMN:CLI User Manual

V8102

906

| Released Nos Image on SFU |

-------------------------------------

* GPIU Released Nos

Version : 3.01

Revision : 1025

Size : 9078904

* SFU Released Nos

Version : -

Revision : -

Size : 0

14.2.2 Auto Upgrade

Upgrade SIU by enabling IU auto upgrade using the following command.

Command

Mode

Description

slot upgrade-mode iu

SLOT_NUMBER auto

Global

Enable IU auto upgrade function.

SLOT: IU slot number, 1 to 2

slot upgrade iu SLOT_NUMBER

Select a slot number of IU and performs the upgrade.

When auto upgrade function is enabled, the V8102 compares the downloaded SFU firm-

ware in the system with the firmware currently loaded in the inserted SIUs. If the version

of the firmware from IU side is lower than that of the firmware from the SFU side, then the

firmware upgrade will automatically start.
