UMN:CLI User Manual

V8102

322

Command

Mode

Description

show vlan

Enable

Global

Shows all VLAN configurations.

show vlan <1-4094>

Shows information of selected VLAN

show vlan brief

Shows VLAN information for all bridges

show vlan description

Shows a description for specific VLAN.

show vlan macbase

Shows MAC configurations.

show vlan {static | dynamic}

[bridge <1-32>]

Shows the static / dynamic VLANs.

show vlan dot1q-tunnel

Shows QinQ configuration.

show vlan protocol

Shows VLAN based on protocol.

show vlan range-tagging in-

bound [PORTS]

Shows VLAN range based tagging configuration.

PORTS: port number

show vlan reserved

Shows the assigned VLAN IDs for the port/sub-

interfaces.

show vlan subnet

Shows VLAN based on subnet.

show vlan interface [{tengiga-

bitethernet | gpon | chan-

nelgroup} IFPORT]

Shows information of VLAN interface.
