no debug ipv6 rip nsm

Disables RIP NSM debugging.

no debug ipv6 rip packet [recv |

send]

Disables a debugging of RIP packets.

no debug ipv6 rip packet [recv |

send] detail

To display the debugging information, use the following command.

Command

Mode

Description

show debugging ipv6 rip

Enable

Global

Shows the debugging information of RIP.
