CP60 and CP60 Plus Service Manual 2-27
Character Encoding
7-bit Alphanumeric Character Set as Defined by ISO/IEC 7811
Code Description
H
These 14 characters ! " & ' * + , : ; < = > @ _ are reserved for hardware control and
cannot be part of the data content. (These may or may not be used by different
device manufacturers.)
R Additional reserved characters.
S,E,F Reserved characters for Start Sentinel, End Sentinel, and Field Separator
Binary
Note Char Parity
2
5
2
4
2
3
2
2
2
1
2
0
Space 1 0 0 0 0 0 0
H ! 0 0 0 0 0 0 1
H " 0 0 0 0 0 1 0
R # 1 0 0 0 0 1 1
$ 0 0 0 0 1 0 0
S % 1 0 0 0 1 0 1
H & 1 0 0 0 1 1 0
H ' 0 0 0 0 1 1 1
( 0 0 0 1 0 0 0
) 1 0 0 1 0 0 1
H * 1 0 0 1 0 1 0
H + 0 0 0 1 0 1 1
H , 1 0 0 1 1 0 0
- 0 0 0 1 1 0 1
. 0 0 0 1 1 1 0
/ 1 0 0 1 1 1 1
0 0 0 1 0 0 0 0
1 1 0 1 0 0 0 1
2 1 0 1 0 0 1 0
3 0 0 1 0 0 1 1
4 1 0 1 0 1 0 0
5 0 0 1 0 1 0 1
6 0 0 1 0 1 1 0
7 1 0 1 0 1 1 1
8 1 0 1 1 0 0 0
9 0 0 1 1 0 0 1
H : 0 0 1 1 0 1 0
H ; 1 0 1 1 0 1 1
H < 0 0 1 1 1 0 0
H = 1 0 1 1 1 0 1
H > 1 0 1 1 1 1 0
E ? 0 0 1 1 1 1 1
Binary
Note Char Parity
2
5
2
4
2
3
2
2
2
1
2
0
H @ 0 1 0 0 0 0 0
A 1 1 0 0 0 0 1
B 1 1 0 0 0 1 0
C 0 1 0 0 0 1 1
D 1 1 0 0 1 0 0
E 0 1 0 0 1 0 1
F 0 1 0 0 1 1 0
G 1 1 0 0 1 1 1
H 1 1 0 1 0 0 0
I 0 1 0 1 0 0 1
J 0 1 0 1 0 1 0
K 1 1 0 1 0 1 1
L 0 1 0 1 1 0 0
M 1 1 0 1 1 0 1
N 1 1 0 1 1 1 0
O 0 1 0 1 1 1 1
P 1 1 1 0 0 0 0
Q 0 1 1 0 0 0 1
R 0 1 1 0 0 1 0
S 1 1 1 0 0 1 1
T 0 1 1 0 1 0 0
U 1 1 1 0 1 0 1
V 1 1 1 0 1 1 0
W 0 1 1 0 1 1 1
X 0 1 1 1 0 0 0
Y 1 1 1 1 0 0 1
Z 1 1 1 1 0 1 0
R [ 0 1 1 1 0 1 1
R \ 1 1 1 1 1 0 0
R ] 0 1 1 1 1 0 1
F ^ 0 1 1 1 1 1 0
H _ 1 1 1 1 1 1 1
