DataCard CP60 - Transport Speed; YMC, K, T, & F Strobe Duty

CP60 and CP60 Plus Service Manual 5-13
 This value is best modified in the printer driver interface under the Edge to
Edge tab.
Range
-15 to 15
Increase Value The printed image moves toward the right on a portrait-
oriented card.
Decrease Value The printed image moves toward the left on a portrait-
oriented card.
Transport Speed
This parameter controls the speed of the transport motor during card transport
but not during printing.
 Altering this parameter can cause resonance in the printer and/or increase
audible noise of the printer. This parameter should not be changed without
contacting technical support.
Range
150 to 3000
YMC, K, T, & F Strobe Duty
These parameters are used to maintain a consistent print intensity between full
columns and partial columns (YMC=Yellow, Magenta, Cyan; K=Black;
T=Topcoat; F=Fluorescent).
 These parameters should not be changed. However, if one parameter is
altered, all three should be altered accordingly.
Range
0 to 255
Increase Value
Columns with fewer pixels print darker.
Decrease Value
Columns with fewer pixels print lighter.
The shaded area directly above and below the white
square on the service test card prints light.
• Increase the YMC strobe setting.
The shaded area directly above and below the white
square on the service test card prints dark.
• Decrease the YMC strobe setting.
Symptom/Solution
K-panel horizontal lines drop out but vertical lines print
properly.
• Increase the K-strobe setting.
