4-6 Troubleshooting
Testing the Printhead Fan
To test the printhead fan, it can be connected to the cam motor’s connection.
These two motors are not compatible, but the driver circuitry for the cam motor
will operate the fan.
CAUTION: You cannot connect the cam motor into the fan’s connector. The
circuitry of the control board will be damaged.
Testing Transport and Duplex Motors
The two stepper motors cannot be tested using the methods presented above.
The only reliable way of verifying if the motor is non-functional is to replace the
motor with another identical motor.
Troubleshooting Other Devices
Testing the Smart Card Solenoid
The driving circuitry for the smart card solenoid is located on the smart card
daughter board. A power transistor on the daughter board amplifies the signal
going to the solenoid. If the solenoid is not receiving a signal, the daughter board
is the likely cause. To verify that the solenoid itself is functioning, plug it into the
cam motor’s connector.
CAUTION: Do not attempt to connect the solenoid into the printhead fan’s
connector, as this may damage the fan’s driving circuitry.
