DataCard CP60 - Duplex Home Offset; Duplex Print Return Offset; Duplex Handoff Offset; Smart Card Registration Offset

CP60 and CP60 Plus Service Manual 5-15
Duplex Home Offset
This parameter controls where the duplex flipper stops when in the home
position.
 Refer to the Duplex Rotational Adjustment procedure (p. 5-39).
Range
1 to 40
Increase Value The index pointer moves toward the lower letters (see the
adjustment procedure).
Decrease Value The index pointer moves toward the higher letters (see the
adjustment procedure).
Duplex Print Return Offset
This parameter controls where the duplex flipper stops when in the print return
(flipped) position.
Range
1 to 70
Value
Home Offset plus 6
 Adjust the Duplex Home Offset, and then set this value to be 6 units larger.
Duplex Handoff Offset
This parameter controls where the duplex flipper stops when in the vertical
handoff position.
Range
70 to 130
Value
Home Offset plus 77
 Adjust the Duplex Home Offset, and then set this value to be 77 units larger.
Smart Card Registration Offset
This parameter controls the distance a contactless smart card travels to reach the
programming station. Because of the nature of the contactless programming
operation, this parameter need not be precise. This parameter should not be
changed and is available only to the Advanced User.
Range
0 to 6000
 The approximate position of the contactless smart card should be the same as
a contact smart card. If this position cannot be determined, set the offset so
the trailing edge of the card covers the location of the magnetic head but does
not cover the location of the magnetic head's pivot pin.
