Chapter 1 - Overview -
AS-410M Auto Slide Preparation System
27
Main functions available
Sample
identification
function
(BR unit)
<Slide printer unit>
Printer (Thermal printer or Dot impact printer)
Printer LEFT/RIGHT drive
Printer shaft UP/DOWN drive
<Barcode reader unit>
Sample barcode reader
Slide barcode reader
Option
Auto trimming (Auto
surface detection
function)
(FS unit)
CCD camera (USB)
Camera lens
LED bar light
LED flat light
Serial cable
PC
Option
External link
Expanded pack (LK-
400)
PC (desktop, with monitor)
Expansion LAN board
LAN cable
Option
Mounting 2 sections
(TM unit)
Three-way solenoid valve
Double dropping nozzle unit
Option
Block surface
temperature
detection (BT unit)
Block surface temperature sensor head
Block surface temperature controller
Option
Blade mark check
(DB unit)
CCD camera (USB)
LED light
×
2
Serial cable
PC
Option
System dimensions (footprint) and unit weight
Main Unit
+
100-slide dry chamber
option (DU-100)
1,280 mm wide × 700 mm deep × 1,980 mm high
(2,180 mm wide × 1,600 mm deep × 2,030 mm high)
Approx. 800 kg
Main Unit
+
100-slide dry chamber
option (DU-100)
+
96-sample feeding option
(BS-96)
1,680 mm wide × 700 mm deep × 1,980 mm high
(2,580 mm wide × 1,600 mm deep × 2,030 mm high)
Approx. 950 kg
Main Unit
+
400-slide dry chamber
option (DU-400)
1,550 mm wide × 700 mm deep × 1,980 mm high
(2,450 mm wide × 1,600 mm deep × 2,030 mm high)
Approx. 900 kg
Main Unit
+
400-side dry chamber
option (DU-400)
+
96-sample feeding option
(BS-96)
1,950 mm wide × 700 mm deep × 1,980 mm high
(2,850 mm wide × 1,600 mm deep × 2,030 mm high)
Approx. 1,050 kg
Cooling unit
Ceiling equipped
Setting temperature range: 20℃ to 55℃
Refrigerant: R134a
Power source
AC100/110/120/220/230/240V single-phase 50/60Hz
1.5KVA×2 system
Supply voltage is set at the time of shipment by the manufacturer.
Working temperature range
(ambient temperature)
10℃ to 28℃
