Chapter 2 - Installation -
AS-410M Auto Slide Preparation System
35
2-1 Unpacking and parts check
This System comes complete with the accessories shown below. Unpack and make sure that none
of the accessories is missing. In the case of any missing accessories, contact us immediately. The
following tables list the System accessories and their quantities:
Sample tray Slide cassette Slide collection box
System with 24-sample feeding option: 1 pc.
System with 96-sample feeding option: 4 pcs.
System with 100-slide feeding (standard): 1pc.
System with 400-slide feeding option: 4 pcs.
System with 100-slide dry chamber option: 1pc.
System with 400-slide dry chamber option: 4pcs.
Dedicated microtome blade cassette
Slide tray Used-blade collection box
1 set (50 pc./cassette)
With 100-slide dry chamber option: 20 pcs.
With 400-slide dry chamber option: 80 pcs.
1 pc.
Waste fluid tank Humidifying water bottle Application medium bottle
1 pc.
1 pc.
1 pc.
To Next Page
