Chapter 4 - Operational Procedures -
AS-410M Auto Slide Preparation System
97
4-3-3 Mount setting
Setting the dripping position and amount and the mounting position of a tissue specimen in the
DRIP SETTING screen.
The section adhesion strength to the carrier tape can be set in three levels by parameters.
One-section mounting
Two-sections mounting
When the Dual Slide Mounting option is available, and the setting is set as ON , the second section
will be mounted on the same slide following the first one.
Table 4-4 Settings of section mounting
On-screen item Setting item Description Setting range
FIRST MOUNT
SETTING
Mounting on slide Specify here the position for mounting a section to the slide as
measured from the left edge of the slide.
0 to 76 (mm)
Tape position
(descent)
Specify here the amount of descent range by which the rollers lower
the tape held in between until the first section is transferred from the
tape to a slide.
-10.0 to 60.0
(mm)
Normal block Specify here the mounting position of the normal block.
Small block Specify here the mounting position of the small block.
Dripping amount Setting of drip amount from Piezo pump.
SECOND MOUNT
SETTING
(Option)
Mounting on slide Setting the distance between first section and second section.
0 to 76 (mm)
Tape position
(descent)
For the second section mounting, specify here the amount of
descent range by which the rollers should lower the tape held in
between until the first section is transferred from the tape to a slide.
-10.0 to 60.0
(mm)
DRIP SETTING screen
PARAMETER SETTING screen
To Next Page
