Chapter 5 Errors and Troubleshooting
204
AS-410M Auto Slide Preparation System
5-3-5 Dry Chamber errors
Error
code
On-screen message Possible cause Solution
5001
<Error Message>
Unit: Dry Chamber
Part: Slide collection box UP/DOWN
Symptom: Overrun
An overrun error occurred in
the dry chamber Z-axis motor
(100-slide dry chamber).
•Take out the slide collection box
and remove obstacles in the
UP/DOWN drive direction.
•Set the slide collection box
correctly.
•Press the HOME POSITION
button to initialize.
5002
<Error Message>
Unit: Dry Chamber
Part: Slide collection box FWD/BWD
Symptom: Overrun
An overrun error occurred in
the dry chamber Y-axis motor
(100-slide dry chamber).
5003
<Error Message>
Unit: Dry Chamber
Part: Slide collection box UP/DOWN
Symptom: Limit
A limit error occurred in the dry
chamber Z-axis motor (100-
slide dry chamber).
5004
<Error Message>
Unit: Dry Chamber
Part: Slide collection box FWD/BWD
Symptom: Limit
A limit error occurred in the dry
chamber Y-axis motor (100-
slide dry chamber).
5005
<Error Message>
Unit: Dry Chamber
Part: Slide collection box UP/DOWN
Symptom: Initialization error
The dry chamber Z-axis motor
(100-slide dry chamber) failed
to complete returning to the
home position within 60
seconds.
5006
<Error Message>
Unit: Dry Chamber
Part: Slide collection box FWD/BWD
Symptom: Initialization error
The dry chamber Y-axis motor
(100-slide dry chamber) failed
to complete returning to the
home position within 60
seconds.
5007
<Error Message>
Unit: Dry Chamber
Part: Slide collection box TILT
Symptom: Operation error
The slide collection box TILT
air cylinder (100-slide dry
chamber) failed to complete its
motion within 5 seconds; or the
two position detection sensors
made ON simultaneously.
5008
<Error Message>
Unit: Dry Chamber
Part: Drying unit temperature control
Symptom: Operation error
The temperature sensor is
electrically disconnected or
exposed to an abnormally high
temperature (80°C or higher).
•Set the temperature controller
lower than the specified value
55°C) if higher.
•If the display shows something
other than numbers, contact DNS
for a service.
5009
<Error Message>
Unit: Dry Chamber
Part: Slide collection box UP/DOWN
Symptom: Overrun
An overrun error occurred in
the dry chamber Z-axis motor
(400-slide dry chamber).
•Turn the System power OFF.
•Take out the slide collection box
and remove obstacles in the
UP/DOWN drive direction.
•Turn the System power ON and
complete the initialization and set
the slide collection box.
5010
<Error Message>
Unit: Dry Chamber
Part: Slide collection box FWD/BWD
Symptom: Overrun
An overrun error occurred in
the dry chamber Y-axis motor
(400-slide dry chamber).
5011
<Error Message>
Unit: Dry Chamber
Part: Slide collection box
LEFT/RIGHT
Symptom: Overrun
An overrun error occurred in
the dry chamber X-axis motor
(400-slide dry chamber).
•Turn the System power OFF.
•Take out the slide collection box
and remove obstacles in the
LEFT/RIGHT drive direction.
•Turn the System power ON and
complete the initialization and set
the slide collection box.
5012
<Error Message>
Unit: Dry Chamber
Part: Slide collection box UP/DOWN
Symptom: Limit
A limit error occurred in the dry
chamber Z-axis motor (400-
slide dry chamber).
•Turn the System power OFF.
•Take out the slide collection box
and remove obstacles in the
UP/DOWN drive direction.
•Turn the System power ON and
complete the initialization and set
the slide collection box.
To Next Page
