Chapter 3 - Preoperational Setup -
AS-410M Auto Slide Preparation System
59
3-7 Setting the application medium bottle in place
Follow the steps below to fill the supplied application medium bottle with water and set the bottle in
the Main Unit.
① Remove the cap of the supplied application medium bottle. Fill the bottle with 250 ml of
application medium. Place the cap back on.
* The cap has a joint and a filter.
② Open the right door of the Main Unit and set the application medium bottle on the bottle holder.
For application medium, use purified water such as distilled water (10 to 30°C).
Do not use tap water or any other liquid. Failure to comply may result in system
failure (breakdown or reduced performance) or an accident (fire, electric shock,
or other negative impacts on the human body).
Wipe with a cloth in case of water leakage. Replace the bottle when damaged.
Right door (R)
Cap
Open
Close
Joint
Filter
Application medium bottle holder
！ Caution
To Next Page
