6-4 Infinity Vista VF6
6 TRENDS
STEPS: Calling up Trend Graphs
1. Press the Menu fixed key.
2. Click on
Review.
3. Click on
Trend Graphs.
STEPS: Navigating the Trend Graphs Screen
z Up and down arrows — scroll through the available parameters one page at
a time.
z Left and right single arrows — move the trend window to the oldest or the
most recent trend data.
z Left and right double arrows — scroll through older or more recent trend
data.
z Hour button — select a trend window of 1, 2, 4, 8 or 12 hours. A smaller
time scale (i.e. 1 hour) displays more detail than a larger time scale (i.e. 12
hours). The time-stamps on the horizontal time axis reflect the scale selected.
z Cursor — display or hide a vertical cursor. Turn the rotary knob to move the
cursor to a specific location (time) on the trend graphs screen. The stored
trend values corresponding to that location appear to the right of the trend
display channels.
z Tabular — call up the Trend Table.
NOTE: You can also call up the Trend Graphs by pressing the Fast Access fixed key.
NOTE: If you try to scroll past the end of the trend graphs screen, the monitor emits
an error tone.
