INFINITY VISTA DISPLAY
VF6 Infinity Vista 1-13
Infinity Vista Display
Alarm Colors
Colors are used to call your attention to important events:
z Black letters on a red background are used for life-threatening alarms and
their messages (e.g., Asystole).
z Black letters on a yellow background are used for serious alarms and their
messages (e.g., Rsp Too High).
z Black letters on a white background are used for advisory alarms and their
messages (e.g., Rsp Lead Off).
z Amber letters on a dark gray background are used for network messages (see
the Network Applications chapter for details).
z White letters on a blue background are used for messages and information
unrelated to the network (e.g., Battery Charging).
1 Message Area 3 Waveform Channels
2 Parameter Boxes
