OVERVIEW
VF6 Infinity Vista D-3
Basic System Components
Monitor Base Unit
Dimensions 196 mm height (7.7 in)
267 mm width (10.5 in)
147 mm depth (5.8 in)
Weight 3.87 kg (8.54 lb) with lead acid battery
3.67 kg (8.10 lb) with lithium ion battery
3.32 kg (7.32 lb) without battery
Materials Plastics: ABS, FR 110
Printed Circuits: glass/epoxy, lead/tin solder, copper etch,
lithium battery
Battery: sealed lead acid, or lithium ion (option)
Heatsink: cast aluminum
NBP assembly: silicon tubing, steel, copper wire
Packing: corrugated cardboard, urethane foam
Disposal All materials must be disposed of or recycled properly and in
accordance with local regulations. There are no known
special disposal requirements for any accessories.
Battery Pack Lead Acid: PANASONIC LC-T121R8PU or equivalent
Li-ion: Dräger Li+ Battery Pack
Protection Class Internally powered, for use with specified Class I power
supply
Mode of Operation Continuous (with AC adapter)
DC Input 11 – 15 VDC, 2.5A
Max. Power Consumption 52 Watts
Battery Operating Time
(with ECG, SpO2, Respiration
waveforms and NBP in a 15-
minute interval mode starting with
a fully charged battery)
Lead acid: 75 minutes
Lithium ion: 210 minutes in Bright Screen Mode and 240
minutes in Dim Screen Mode
Battery Recharging Time Lead acid: 5½ hours, typical.
Lithium ion: 8 hours, typical.
Patient Leakage Current < 10PA @ 110 V and 60 Hz
< 10PA @ 220 V and 50 Hz
QRS Sync. Output Output will go high for 100 ms every time a QRS is detected.
QRS detected: +12 V ±5%, 5.1 K: source impedance.
Output low (no QRS): < .8 V @ 30 mA sync current.
Alarm Output 12 V 560 : output for external alarm indicator (Nurse Call
System)
Recorder UART output to interface with an R 50 Series recorder
through the interface plate.
