STORED R ECORDINGS
VF6 Infinity Vista 7-13
Stored Recordings
The monitor can store up to 10 alarm or timed recordings consisting of 20 seconds of
data each (about 10 seconds of pre-event/request data and about 10 seconds of post-
event/request data.) Recordings are stored when:
z No recorder/laser printer is available or if the recorder/laser printer is
temporarily out of order (i.e. no recording paper).
z You turned on the automatic storage of alarm recordings on the Alarm Limits
table (see the chapter Alarms and Messages).
When the recording storage is full, the monitor deletes the oldest unsaved recordings
as new recordings come in. You can view, print, save, and delete stored recordings via
the Event Recall screen (see below).
Upon successfully storing a recording, the monitor emits 2 beeps. To cancel a
recording storage in progress, press the
Record fixed key on the monitor within 5
seconds of the start of the recording storage.
Event Recall
You can view 4 seconds of waveform data for each stored recording on the Event
Recall screen (4 seconds of pre-event/request data). The screen also shows the
parameter values at the time of the recording storage.
To call up the Event Recall screen:
1. Press the
Menu fixed key.
2. Click on
Review.
3. Click on
Event Recall.
NOTE: The monitor does not store continuous, trend, OCRG or diagnostic log
recordings. Continuous recordings are converted to timed recordings and then stored.
NOTE:
z You can also access the Event Recall screen via the Fast Access fixed key or by
clicking on Monitor Setup > Recordings > Review in the Main Menu.
z The Event Recall screen shows only 4 seconds of data for each stored
recording, although the monitor has actually stored 20 seconds of data for each
stored recording. If you print the stored recording, the recording strip contains
all 20 seconds of stored data.
