6-6 Infinity Vista VF6
6 TRENDS
STEPS: Navigating the Trend Table
z Up and down arrows — scroll through the available parameters one page at
a time.
z Left and right single arrows — move the trend window to the oldest or the
most recent trend data.
z Left and right double arrows — scroll through older or more recent trend
data.
z Minutes (Min) — select a trend window of 1, 5, 15, 30 or 60 minutes. Data
columns are spaced according to the selected window.
z Graphical — call up the Trend Graphs screen.
Special Conditions and Codes
When a parameter is not monitored during a trend sampling interval, the value is blank
on the trend display.
When alarms are enabled, the monitor stores and displays the first occurrence of the
alarm with the highest priority detected during the one-minute trend sampling interval.
Trend storage and display priorities are as follows:
1. Power-up, testing, and standby.
2. Life-threatening alarms (i.e. ASY, VT, VF).
3. Out-of-range conditions (+++ or ---).
4. Serious alarms: Alarm limit violations and apnea.
5. Advisory alarms: Artifact and lead-off conditions.
For conditions that fall under the same priority, the monitor stores and displays the
first condition detected during the trend sampling interval.
Life-threatening alarms are marked by a small dot on the bottom of the HR trend
channel on the Trend Graphs screen.
Technical conditions show a gap on the trend displays and the trend value is replaced
by one of the technical codes listed below.
NOTE:
z Completed NBP measurement add an extra column to the table.
z If you try to scroll past the end of the trend table, the monitor emits an error
tone.
