2-8 Infinity Vista VF6
2 MONITOR SETUP
Assembling MULTIMED and NEOMED Pods
Choose a 5-lead or 6-lead MULTIMED Pod (adult/pediatric applications) or a NEOMED
Pod (neonatal applications) for your monitoring session. Assemble the pods as
illustrated prior to connecting them to the monitor. (Parameter-specific patient
preparation is described in the individual parameter chapters.)
1) SpO
2
sensor 2) ECG lead sets 3) Temperature sensor
NOTE: The FiO
2
and TEMP B connectors of the NEOMED™ pod are not supported
with the Infinity Vista monitor.
WARNING: Do not use the NEOMED Pod during electrosurgery.
Use during cautery may result in burns to the patient or
clinical staff.
