D-4 Infinity Vista VF6
D TECHNICAL DATA
Monitor Display
Type Color Liquid Crystal Display (LCD)
Size 8.4 " (21 cm)
Display Area 170.9 mm x 129.6 mm
Matrix 640 x 480 pixels
Pixel Pitch 0.267 x 0.270 mm
Number of Channels 4
Sweep Speeds Fixed 25 mm/s ±20% for ECG, SpO
2
, and IBP curves
Fixed 6.25 mm/s ±20% for Resp curve
Fixed 1.0 mm/s ±20% for optional OCRG curve
Display Mode Erase bar (updates waveforms from left to right)
Environmental requirements (Base Unit and AC Power Adapter)
Cooling Convection and cooling chimney (no fan)
Temperature Operating: 0 qC to +45 qC (without recorder)
Storage: –20 qC to 50 qC
Relative Humidity Operating: > 10% and < 95%, non-condensing
Storage: > 10% and < 95% non-condensing
Altitude Operating: -381 to +3048 m (-1250 to +10000 ft.)
525 to 795 mmHg (70 to 106 kPa)
Storage: -381 to +5486m (-1250 to +18000 ft.)
375 to 795 mmHg (50 to 106 kPa)
Transportation
(with shipping package)
Per National Safe Transit Association (NSTA)
Sinusoidal Vibration Operating: IEC 68-2-6; 0.040 inch DA,
5 to 32 Hz; 2G peak 32 to 500 Hz
Storage: per ISTA procedure 1
Drop Free fall: 250 mm, 28 repetitions
Shock IEC 68-2-27 50 G, half sine, 11ms, 18 reps
Water Resistance Drip-Proof (IPX 1)
