CUFF SELECTION AND PLACEMENT
VF6 Infinity Vista 13-5
To avoid kinks in the hose, center the cuff bladder on
the artery so that the hose is to the left or to the right of
the artery.
Connect the NBP cuff and hose to the monitor’s hose
connector on the left side of the device.
1 Cuff Size Indicators 4 Range Labels
2 Artery Label 5 Label: This side to patient
3 Index Line
