Edge-Core ES4524M-POE

Configuring the Switch
3-6
LACP Link Aggregation Control Protocol 3-107
Configuration Allows ports to dynamically join trunks 3-107
Aggregation Port Configures system priority, admin key, and port priority 3-110
Port Counters Information Displays statistics for LACP protocol messages 3-113
Port Internal Information Displays settings and operational state for local side 3-114
Port Neighbors Information Displays settings and operational state for remote side 3-116
Port Broadcast Control Sets the broadcast storm threshold for each port 3-118
Trunk Broadcast Control Sets the broadcast storm threshold for each trunk 3-118
Mirror Port Configuration Sets the source and target ports for mirroring 3-120
Rate Limit 3-121
Input Port Configuration Sets the input rate limit for each ports 3-121
Input Trunk Configuration Sets the input rate limit for each trunks 3-121
Output Port Configuration Sets the output rate limit for each ports 3-121
Output Trunk Configuration Sets the output rate limit for each trunks 3-121
Port Statistics Lists Ethernet and RMON port statistics 3-122
PoE Power over Ethernet 3-127
Power Status Displays the status of global power parameters 3-127
Power Configuration Configures the power budget for the switch 3-129
Power Port Status Displays the status of port power parameters 3-129
Power Port Configuration Configures port power parameters 3-130
Address Table 3-132
Static Addresses Displays entries for interface, address or VLAN 3-132
Dynamic Addresses Displays or edits static entries in the Address Table 3-133
Address Aging Sets timeout for dynamically learned entries 3-135
Spanning Tree 3-136
STA Spanning Tree Algorithm 3-138
Information Displays STA values used for the bridge 3-138
Configuration Configures global bridge settings for STA, and RSTP 3-141
Port Information Displays individual port settings for STA 3-145
Trunk Information Displays individual trunk settings for STA 3-145
Port Configuration Configures individual port settings for STA 3-148
Trunk Configuration Configures individual trunk settings for STA 3-148
Table 3-2 Main Menu (Continued)
Menu Description Page
