Configuring the Switch
3-8
LLDP Link Layer Discovery Protocol 3-176
Configuration Configures basic LLDP time parameters 3-176
Port Configuration Configures a port for receive and, or transmit status, allows
sending of SNMP notification messages, and configures TLV
information.
3-178
Trunk Configuration Configures a trunk for receive and, or transmit status, allows
sending of SNMP notification messages, and configures TLV
information.
3-178
Local Information Displays information about the local device. 3-181
Remote Port Information Displays information about ports on a remote device 3-182
Remote Trunk Information Displays information about trunks on a remote device 3-182
Remote Information Details Sets the port and, or trunk to display information 3-183
Device Statistics Displays device statistics 3-184
Device Statistics Details Allows the user to select the port or trunk on which to display
statistical information
3-185
Priority 3-186
Default Port Priority Sets the default priority for each port 3-186
Default Trunk Priority Sets the default priority for each trunk 3-186
Traffic Classes Maps IEEE 802.1p priority tags to output queues 3-188
Queue Mode Sets queue mode to strict priority or Weighted Round-Robin 3-190
Queue Scheduling Configures Weighted Round Robin queueing 3-191
IP DSCP Priority Status Globally selects IP DSCP Priority, or disables it. 3-192
IP DSCP Priority Sets IP Differentiated Services Code Point priority, mapping a
DSCP tag to a class-of-service value
3-192
QoS Quality of Service 3-194
DiffServ Configures QoS classification criteria and service policies 3-194
Class Map Sets Class Maps 3-195
Policy Map Sets Policy Maps 3-198
Service Policy Defines service policy settings for ports 3-201
IGMP Snooping 3-202
IGMP Configuration Enables multicast filtering; configures parameters for
multicast query
3-204
IGMP Immediate Leave Enables the immediate leave function 3-206
Multicast Router
Port Information
Displays the ports that are attached to a neighboring multicast
router for each VLAN ID
3-207
Table 3-2 Main Menu (Continued)
Menu Description Page
