M1-6 031914
Check the oil level in the pneumatic
lubricator. Fill with white (mineral) oil
when low. DO NOT OVERFILL! Fill
so that the level can be seen in the
sight glass. If the unit is overfilled,
the oiler will not work correctly.
OIL LEVEL
FILL
PORT
LUBRICATOR ADJUSTMENT
KNOB
SET LUBRICATOR TO
MINIMUM FLOW RATE THEN
BACK OFF 1/8 TURN
LUBRICATOR
YV1
LUBRICATION - WEEKLY
