Formax PowerMax 3000 - Scale Manifold

M5-4 031914
SCALE MANIFOLD
The XS4 Scale Manifold is located in the
Scale Cabinet. (Illustration 5) The Scale
Manifold contains the valves for the load cell
seal and the classifer cylinders that raise and
lower the conveyors.
XS4 SCALE
HOUSING
MANIFOLD
ILLUSTRATION 5
