MOVE TO READY POSITION: The “Move To
Ready” button is used to prepare the machine for
operation after clean-up and whenever the
Machine Power is turned “On.” The Infeed
Structure will move to the “Run-Ready” position. All
of the other Slicer components will move to their
“Home” position.
“Touching” and “holding” the “Move To Ready”
button on the “Run” screen sounds the HA1 Safety
Horn as the Slicer components move to “Run” or
“Home” position. (Illustration 3)
1. The M6 Servo Motor raises the Infeed
Structure will raise to the “Up” position.
2. All of the Slicer components will “Align” to
their “Home” position.
2-2 031914
“MOVE TO READY” BUTTON
READY POSITION
ILLUSTRATION 3
STRUCTURE
RAISES
ILLUSTRATION 4
M6
SERVO MOTOR
