SAFETY SYSTEM OVERVIEW

SAFETY ZONES FUNCTION BRANCH CONTACTOR

Main Guard Function Stops all motions KA1/KA2

Clean Function Allows clean motions only:

Structure

KA3/KA4

Safety Laser Scanner Inhibits Motions:

Product Lift Tray

KA7/KA8

KM2

CONTACTOR

KM3

CONTACTOR

KA1/KA2 KA3/KA4 KA5/KA6
