FEEDBACK CONVERTERS
The Servo Motors that are not
manufactured by Siemens, use a
different type of Resolver Feedback.
These Resolver Feedback signals
are first sent to a Feedback
Converter that translates these
signals into a format that that can be
understood by the Siemens Motion
Control Modules. (Illustration 11) The
Motion Control Modules use the
Resolver Feedback signals
generated by the Servo Motors to
monitor and control the Servo Drives
and Servo Motors.
M3-6 5409
ILLUSTRATION 11
U0
FEEDBACK
CONVERTOR
U13
FEEDBACK
CONVERTOR
U14
FEEDBACK
CONVERTOR
U15
FEEDBACK
CONVERTOR
