Formax PowerMax 3000 - Mainframe Manifold

031914 M5-3
MAIN FRAME MANIFOLD
The XS3 Main Frame Manifold is located
in the bottom of the machine cabinet.
(Illustration 3) The XS3 Manifold has the
directional valves that control the Scanner
Cover and the optional pop-up pins on the
Slicing Conveyor.
XS3 LOAF TRAY MANIFOLD
ILLUSTRATION 4
