M5-2 031914
INFEED HOUSING MANIFOLD
The XS5 Infeed Housing Manifold is
located in the Upper Cabinet along with
BP2. (Illustration 2) The Infeed Housing
Manifold contains the valves that
controls the air distribution for the Loaf
Gate, Grippers, and the Loaf Tray.
XS5 INFEED HOUSING
MANIFOLD
ILLUSTRATION 3
