(4) iMFF Setting
Displays the iMFF setting as follows:
Icon Operation mode
- Standard mode
Manual mode
Auto mode 1
Auto mode 2
There is no icon for [Standard mode].
In Manual mode,
is displayed at all times.
In Auto mode 1 and Auto mode 2, it displays the number of overlap patterns memorized.
The number of overlap patterns that can be memorized depends on the operation mode that is described
below:
● For Auto mode 1
In this operation mode, up to four overlap patterns can be memorized at a time (when one sheet is
scanned), and up to 32 overlap patterns can be memorized in total.
When the 33rd overlap pattern is detected, the first pattern that was memorized is overwritten.
However, when turning the scanner off and on, the number of memorized overlap patterns depends on
the setting for [Remember overlap patterns at power-off] in the Software Operation Panel.
For details, refer to Setting to Ignore Certain Overlap Patterns [Intelligent Multifeed Function] (page
386).
● For Auto mode 2
Only one overlap pattern can be memorized in this operation mode.
For details about the iMFF setting, refer to How to Use Settings Menu (page 146).
(5) USB/wired LAN Status
The USB/wired LAN status is displayed as follows.
Icon Connection Status via a USB
Cable
Connection Status via a LAN
Cable (*1)
Network Function Setting
(*2)
Connected Connected Enable
Connected Connected Disable
Connected Not connected Disable
Connected Not connected Enable
Not connected Connected Enable
How to Use the Operator Panel [fi-8190/fi-8290/fi-8170/fi-8270]
144
