b Insert the retaining clip of the other pick roller into the slot.
ATTENTION
Confirm that the pick rollers are attached properly. Otherwise, paper jams or other feeding errors
may occur.
Make sure you insert the pick rollers until they lock in place.
8 Attach the shaft.
