"Disconnecting the power cord" on page
46.
▶
If necessary, remove all external cables from the expansion card.
▶
"Removing the server from the rack" on page 49.
▶
"Getting access to the component" on page 47.
▶
Remove the air duct from the top system board, see "Removing the CPU
air duct" on page 72.
▶
Remove all memory modules, see "Removing a memory module" on
page 263.
Before removing the memory modules, take a note on the installation
slot number for each memory module. Ensure that you install the
memory modules again in the slot they were located before the
replacement.
CAUTION
▶
In case of NVM/LRDIMMs are not reinstalled in the right slots,
data can be lost!
▶
"Removing the riser module 3/4 and 6/7" on page
61.
▶
"Removing the fan cage" on page 69.
▶
"Removing the top system board holder" on page 74.
System board and components
354 Upgrade and Maintenance Manual RX4770 M5
