Install all expansion card to slot 1, 2, and 8, see "Installing an expansion
card" on page 190.
▶
Install the air duct on the bottom system board, see "Installing the CPU air
duct" on page
74.
▶
"Installing the top system board holder" on page 79.
▶
"Installing the fan cage" on page 71.
▶
Install the air duct on the top system board, see "Installing the CPU air duct"
on page 74.
▶
"Installing the riser module" on page 65.
▶
"Installing the riser module 3/4 and 6/7" on page 62.
▶
Install both PSUs, see "Installing a hot-plug PSU" on page 123.
▶
"Reassembling" on page 53.
▶
"Installing the server in the rack" on page 55.
▶
"Connecting the power cord (AC PSU)" on page 58.
▶
Connect all external cables.
▶
"Switching on the server" on page 59.
When the system is powered on after a CPU has been replaced or
upgraded, the Global Error indicator will start flashing with the message
CPU has been changed.
This only indicates that the CPU configuration has been altered. There
is no technical problem.
Proceed as follows:
●
Restart your server
.
●
As soon as the startup screen appears, press the [F2] function key to
enter the BIOS.
●
If a password is assigned, enter the password and press [Enter].
●
Select the Save & Exit menu.
●
Select Save Changes and Exit or Save Changes and Reset.
●
Verify that the Global Error indicator stops flashing.
System board and components
368 Upgrade and Maintenance Manual RX4770 M5
