Field Description
the peer configuration.
Possible values:
• Up (default value): The peer is available for setting up a tunnel
immediately after saving the configuration.
• Down : The peer is initially not available after the configuration
has been saved.
Description Enter a description of the peer that identifies it.
The maximum length of the entry is 255 characters.
Peer Address Enter the official IP address of the peer or its resolvable host
name.
The entry can be omitted in certain configurations, whereby
your device then cannot initiate an IPSec connection.
Peer ID Select the ID type and enter the peer ID.
This entry is not necessary in certain configurations.
The maximum length of the entry is 255 characters.
Possible ID types:
• Fully Qualified Domain Name (FQDN)
• E-mail address
• IPV4 Address
• ASN.1 DN (Distinguished Name)
On the peer device, this ID corresponds to the parameter Local
ID Value.
Preshared Key Enter the password agreed with the peer.
The maximum length of the entry is 50 characters. All charac-
ters are possible except for 0x at the start of the entry.
Fields in the IPSec Peers Interface Routes menu
Field Description
IP Address Assignment
Select the configuration mode of the interface.
14 VPN Funkwerk Enterprise Communications GmbH
224 bintec W1002/W1002n/W2002/WIx040/WIx065
