Field Description
Possible values:
• Static (default value): You enter a static IP address.
• IKE Config Mode: Choose an IP address from the con-
figured IP pool.
IP Assignment Pool Only if IP Address Assignment = IKE Config Mode
Select an IP pool configured in the VPN -> IP Pools menu. If an
IP pool has not been configured here yet, the message Not
yet defined appears in this field.
Default Route Only for IP Address Assignment = Static
Select whether the route to this IPSec peer is to be defined as
the default route.
The function is activated with Enabled.
The function is disabled by default.
Local IP Address Only if Standard Route is not enabled.
Enter the LAN IP address of your device.
Route Entries Define routing entries for this connection partner.
• Remote IP Address: IP address of the destination host or
LAN.
• Netmask: Netmask for Destination IP Address.
• Metric: The lower the value, the higher the priority of the
route (possible values 0...15). The default value is 1.
The Advanced Settingsmenu consists of the following fields:
Fields in the Advanced Settings Advanced IPSec Options menu
Field Description
Phase-1 Profile For phase 1, select a profile already configured in the Phase-1
Profiles menu. You can also select the profile marked as the
default in Phase-1 Profiles: None (use Default
Profile).
Funkwerk Enterprise Communications GmbH
14 VPN
bintec W1002/W1002n/W2002/WIx040/WIx065 225
