2) Define the System’s Parameters
Action
Screen
• Identify the system type (Standalone, A-B, N+1, IP
Only).
• Set system-wide volume and attenuation levels.
• Assign the controller’s network settings such as IP
address (static) or enable DHCP.
• Enable/disable event recorder.
• Set the maximum mute duration.
• Set the maximum attenuation duration.
• Set the maximum fault acknowledge duration.
• Enable/disable features: mix 2, mix substitution, event
mismatch correction, insert 1 & insert 2.
System Properties (Global Settings on page
12)
3) Define the System’s Hardware Devices
Action
Screen
Add Amplifiers
System Properties → Amplifiers
• Select the amplifier type.
• Edit the amplifier description.
• Set the channel ID (1–64).
• Set channel zone display.
• Enable/disable load testing.
• Identify if channel is a standby amp.
Amplifiers (on page 20)
Add Speaker Masters
System Properties → Speaker Masters
Add Audio Channels.
Speaker Masters (on page 24)
Add Speaker Remotes
System Properties → Speaker Remotes
Create Speaker Remotes.
Speaker Remotes (on page 26)
Add I/O (Input/ Output) Modules
System Properties → I/O Controllers
• Add I/O modules.
• Select I/O module types.
I/O Controllers screen (on page 44)
Add Modbus Modules
System Properties → Modbus
• Configure the E3 Modbus module.
• Add and configure external IP Modbus modules.
Modbus(on page 53)
4) Define the System’s Live Audio Sources
Action
Screen
• Enable Live Audio Sources:
• Page/Party
• telephone interface
• Aux #1–Aux #5
• IP Aux #1–IP Aux #8
Audio Inputs screen (on page 59)
• Set the priority of the audio input sources.
Sources Enabled (on page 59)
