11) Define the System Inputs and Outputs/Add Access Panels
Program the access panel push-button functions from the
access panel button template using the features common to
most panels. (Added access panels inherit the button
template assignments.)
• Select the button function.
• Select the button color.
• Enter the button label text.
System Properties → Access Panels → Access
Panel Button Configuration (on page 32)
Add access panel interface cards and access panels.
System Properties → Access Panels
• Enable API cards (1–4).
• Add access panels to each API card.
• Select the access panel type—each added panel is
initially set to the functions of the access panel button
template.
Access Panel Interfaces Summary screen
(on page 28)
• Edit the access panel description.
• Set the access panel address (0–F).
• Enable/disable supervision.
Access Panel Properties screen (on page 30)
Program the inputs to the I/O controllers:
• Enter a description of the input.
• Select type of switch connected to the input and
cable supervision (if applicable).
• Select the event triggered when the input is active.
• Enable/disable the input’s auto-inhibit function.
System Properties → I/O Controller Properties
→ Inputs Tab (on page 48)
Program the outputs to I/O controllers:
• Enter a description of the output.
• Select the inactive (idle) state of the relay output
(on open or closed).
• Select if the relay should follow the audio play of
the event which triggers the relay.
• Select the cadence of the relay activation (normal,
pulse, or interval).
System Properties → I/O Controller Properties
→ Outputs Tab (on page 49)
12) Configure System Audio Mixing Parameters
• Set the attenuation threshold level.
• Set the mix threshold level.
System Properties → Global Audio Mix Setup
(on page 18)
