Chapter 7 Diagnostics/Troubleshooting 7-11
7-6-1-1 System Doesn’t Boot (cont’d)
Figure 7-7 System Doesn’t Boot (cont’d)
System doesn’t boot! (con’d)
Is “VIVID P3” starting to
display on the LCD?
Go to Scan Procedure section.
NO
Reboot the system and Reload
latest system & Application
software with DVD-RW.
YES
Is BIOS screen displayed
on the LCD?
NO
Is BIOS screen displayed
on external Monitor?
NO
Check flat Ribbon
cable B/W DCK & RPI
YES
1) Check LCD brightness.
2) Check LCD Power & Signal
Cable.
3) Check LCD & Replace if found
defective else replace MST+DCK.
YES
YES
Reboot system, if still
can’t boot up, please
replace TMST assy.
NO
Replace
TMST PWA.
To Next Page
